The EJA430E is a traditional mounted gauge pressure transmitter in our range.
EJA430E features include:
1.± 0.055% accuracy (0.04% accuracy optional)
2.± 0.1% stability per 10 years
3.90 ms response time
4.Exida and TUV SIL 2/3 certification
5.Local Parameter Setting (LPS)
HART 5/7, 1 to 5V HART 7 (low power), FOUNDATION Fieldbus, PROFIBUS PA, or BRAIN communications are available.
Signal Characterization
Signal characterization is a versatile function available on all Yokogawa pressure transmitters. The function is used to compensate the analog 4 to 20 mA output signal for non-linear applications. Such applications include tank strapping or flow measurements; but, it can be used in any application where the relationship between the pressure input and the desired output signal are known. This feature can use up to 10-points.
Advanced Diagnostics
Reduce unscheduled maintenance by 60%.
Predictive impulse line blocking and stream tracing diagnostics lets you see problems before they happen.
Rugged Construction
Ruggedly constructed differential pressure transmitter can help your plant reduce failures. Pressure transmitters have construction features that are designed to allow it to outlive your plant. Four-bolt pressure retaining design, Active DPharp sensor, Teflon coated 316L stainless steel flange gasket, and dual seal certified to ANSI/ISA 12.27.01 - all design features to extend the life of the transmitter.
Product Tags:
|
|
EJA430E Instrument Pressure Transmitter 4-20mA DC Stainless Steel Images
|
